SY215H Pro: It is a powerful mining equipment, which fully transplants the excellent performance of SY225H mining machine. You can buy a 22-ton mining excavator at the price of 21 tons. It uses Isuzu 4HK1 engine, which has the main features of sufficient power reserve and durability. It is equipped with V90N130 large-displacement main pump, which is particularly suitable for mining loading and secondary crushing.
The main pump is upgraded, the 21-ton equipment is equipped with a 25-ton Isuzu engine, and the bucket is equipped with a 1.1 cubic meter bucket as standard! The working efficiency of the equipment is improved, the pressure is increased, and the digging force is increased (from 34.3Mpa to 37Mpa); one excavator can achieve the results of multiple excavators.
The SY215H excavator adopts a large bucket capacity of 1.1 cubic meters, the largest in the same tonnage class, and the loading capacity is increased by more than 10%.
Use enhanced working device. Optimize the hinge point of the working device and adopt a new bucket to optimize the bucket shape, reduce the digging resistance, and solve the problem of inability to dig hard soil. Upgraded tooth pin gasket: Optimize the structure of the bucket pin gasket to greatly reduce the problem of bucket tooth falling off. High-strength and high-hardness bucket teeth, guard teeth and side teeth ensure the wear resistance of the bucket under severe impact and vibration conditions.
Specifications:
| Year | Brand | Model | Operating weight | Bucket capacity | Engine | Power | Max.Digging depth | Track shoe width | Cooling method |
| 2021 | SANY | SY215H | 22800KG | 1.1-1.15 m3 | Isuzu 4HK1 | 133KW | 6450mm | 800mm | Water Cooling |
