2023 year 25tons crane
used XCMG truck cranes
FOB Price: USD49K/Negotiation
We also provide other model cranes
XCMG QY25K5D 25 ton used truck crane the operations of crane are very simple, convenient and flexible. It is widely used for lifting operation and installation work in urban renewal, transportation, ports, bridges, oilfield, industrial and mining enterprises, etc.
Truck crane QY25K5D adopts U-shaped cross-section boom has small depth-width ratio, strong bearing capacity, small deformation,strong anti-bending and powerful lifting capacity.The main boom length is 10.6m to 41.0m, the performance of mid-extended boom and fully-extended are also superior.
Truck crane QY25K5D embedded sliders are equipped, which enlarge the contact square and reduce the contact stress of boom.
Truck crane QY25K5D with 9-speed transmission equipped, it has superior travel and grade ability. The max. grade abilityis 40%, max. travel speed is 90 km/h.
Efficient operation and fast transition, improved boom extension efficiency: the new rope telescopic control technology is adopted, only one enhanced telescopic cylinder is needed, the boom's deadweight is reduced, and the full extension time is only 55 seconds, which is 40-50% more efficient than the traditional design.
Compact body design: meets more than 98% of road restrictions (such as bridges, tunnels, residential areas, etc.), and can carry full counterweight for short-distance transfer, reducing truck and labor costs.
Specifications:
| Year | Model | Brand | Max. Related Lifting Capacity | Max. Allowable Total Mass | Engine model | Engine power | working hours | Made place | Dimension |
| 2023 | QY25K5D-5 | XCMG | 25000 KG | 31470 KG | SC7H300Q6P | 218KW | 1712 HRS | China | 12780*2500*3400mm |
