HD325-6

Engine:Komatsu SAA6D140E-3

Power:364 kw

Capacity:18-24 m3

Technical characteristics

Introduce

The Komatsu HD325-6 is a sturdy, spoke-type truck equipped with a powerful Komatsu engine, which has excellent durability and operating comfort. It also uses a large-capacity oil-cooled wet multi-plate reducer, which allows the vehicle to have a higher downhill speed and a longer continuous downhill distance. It uses the Komatsu K-ATOMCS transmission, which has no impact on speed shifting, and coupled with the hydro-pneumatic composite suspension, it can achieve smooth driving and shifting.

Advantages

High reliability and durability: Komatsu HD325-6 adopts a sturdy hopper and a cast steel frame, which can ensure high reliability and durability even in harsh working conditions.

‌Efficient power system‌: This model is equipped with a large-capacity oil-cooled wet multi-plate reducer, which allows the vehicle to go faster when going downhill and for longer continuous downhill distances.

Advanced transmission system: Komatsu HD325-6 uses AC transmission components. This technology makes the vehicle more stable during driving, while improving the efficiency and reliability of the vehicle.

‌Powerful carrying capacity‌: The rated load capacity of this model is 36,500 kg, the full load mass is 66,500 kg, and the loading capacity is 24 cubic meters (stacked)/18 cubic meters (flat packed), which can meet the needs of large-scale mining operations‌

Performance Parameter

Specifications:

Model Style Brand Engine Power

Empty Weight

Working hours

Load Capacity

Number Of Cylinders

Dimension
HD325-6 Dump truck Komatsu SAA6D140E-3 364 kw 31280kg / 24 m3 6 8700*4525*4280mm
