Technical characteristics

Low Fuel Consumption and High Performance

Compared with 330D2 excavator working in similar applications, it can save up to 10% fuel.

Standard Cat technology can reduce operator fatigue and save operating costs (including fuel consumption and routine maintenance), thus improving operating efficiency by as much as 45%.

C7.1 Engine can use biodiesel up to B20, which meets the four off-road emission standards of China.

Use two power modes to match the excavator with the operation; And automatically match the engine and hydraulic power with the excavation conditions through Smart mode.

Auxiliary hydraulic options provide you with the versatility you need to use a wide range of Cat tooling.

Maintenance Cost Reduction

Compared with 330D2, it is estimated that the maintenance cost can be reduced by as much as 25% (saving data is calculated based on 12,000 machine hours).

Use the engine dipstick close to the ground to check the engine oil level quickly and safely; With the second dipstick at your fingertips, you can fill and check the engine oil at the top of the machine. The service life and maintenance cycle of the excavator's filter can be tracked by the monitor in the cab.

Using original Cat oil and filter and carrying out typical S∙O∙S monitoring can extend the current maintenance interval to 1000 hours, which is twice as long as before, so that you can get longer normal operation time and complete more work.

The latest air intake filter with pre-filter is expected to last for 1000 hours-the service life is 100% longer than that of the previous filter.

The latest hydraulic oil filter can provide better filtration performance, and the reverse discharge valve can keep the oil clean when replacing the filter, and the replacement interval is as long as 3,000 man-hours, and the service life is longer-50% longer than the previous filter design.

High-efficiency cooling fans only run when needed; You can set the interval so that it can automatically reverse to keep the radiator core clean without interrupting your work.

The S·O·S SM sampling port simplifies the maintenance work and can quickly and easily extract oil samples for analysis.

Easy to Operate

The engine can be started through the button, Bluetooth® key card or unique operator ID function.

Use the operator ID to set the power mode and joystick preferences; The excavator will remember these preferences every time it works.

Fast navigation can be achieved with the help of a high-resolution 203 mm(8 in) standard touch screen monitor or knob control device.

To prevent hydraulic hammer from overload operation. Automatic stop signal of hydraulic hammer will continuously warn for 15 seconds, and then automatically close hydraulic hammer after 30 seconds, so as to prevent wear of tooling and excavators.

Don't know how a function works or how to maintain the excavator? You can access the operator's manual at any time simply by moving your finger on the touch screen monitor.

Find the tool you need-even if it is hidden under grass or debris. The provided Bluetooth reader can search any tooling equipped with Cat asset tracking equipment, and the search range can reach 60 m(200 ft).

Safer

Thanks to the smaller cab column, wide window and flat hood design, the operator can get excellent vision no matter inside the ditch, in each turning direction or behind. A rear view camera is standard, and a right camera is available.

The design of the right maintenance platform is convenient to reach the upper maintenance platform easily, safely and quickly; Non-slip perforated plates are used for the maintenance platform steps to prevent slipping.

When the standard hydraulic locking lever is in the lowered position, all hydraulic functions and travel functions will be blocked.

Once the ground stop switch is activated, the fuel supply to the engine will be completely stopped and the machine will be shut down.

Enhance the safety of the job site. A rotary alarm is installed to remind relevant personnel when rotating from the ditch to the pile and back.

Performance Parameter

Brand

Model

Year

Operating mass

Width

Working Hours

Engine Brand

Engine Power

Country of Origin

Remark

CAT

330GC

2022

31TON

1.6m³

BRAND NEW

Cat® C7.1

151Kw

CHINA

brand-new
